This complete single storey residential house plan is designed for comfort and efficient space use. It provides a simple layout that is easy to understand and construct.
The house includes a porch, sitting room, dining area, kitchen, bedrooms, a master bedroom with storage, toilets, bathrooms, and a store. Corridors allow smooth movement between rooms and improve privacy.
The drawing set includes a ground floor plan, roof plan, elevations, and building sections. It also provides septic tank details, soak pit drawings, inspection chambers, strip foundation details, and roof truss information. Window and door schedules are clearly shown.
Construction notes are included for the foundation, floor slab, walls, and roof. These notes help guide proper construction on site. The plan can be adjusted to meet local building regulations and personal requirements.
This house plan is suitable for private residential development and family housing projects.
What’s Included (Product Highlights)
Ground floor plan
Roof plan
Elevations (A, B, C, D)
Building sections
Window and door schedule
Septic tank details
Soak pit details
Inspection chamber and manhole details
Strip foundation drawings
Roof truss details
General construction notes
